092695 Euchner Limit Switches
Part#:092695
Alt. Part#:EGT1M12-2000
Manufacturer:Euchner
Category:Limit Switches
Product Lifecycle:Active
Product description
092695 Euchner - SINGLE HOLE LIMIT SWITCH
Product Details
- Weight 0.40131 lb
- Rated impulse withstand voltage Uimp 2,5 kV
- Switching voltage 12 V
- Connection cross-section 0,5 mm²
- Short circuit protection according to IEC 60269-1 2A gG
- Rated insulation voltage Ui 250 V
- Switching current 10 mA
- Utilization category acc. to EN 60947-5-1 0.6A 24V
- Actuating force 20 N
- Actuating element Ball plunger (Short)
- Approach speed 0,01 ... 8 m/min
- Connection PUR cable (Four-core)
- Cable length 2 m
- Number of NO contacts 1 (Changeover contact)
- Number of NC contacts 1 (Changeover contact)
- Installation orientation Any
- Contact material Silver alloy, gold-plated
- Switching principle Snap-action switching contact
- Cable ambient temperature (static) -25 ... 80 °C
- Repeat accuracy (absolute) ±0,01 mm (On axial actuation in the retracted state after approx. 2000 operating cycles)
- Housing material Brass, nickel-plated
- Mechanical life 1 x 10⁶
- Design Thread M12 x 1
- Degree of protection IP67
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 092695 on MQ Automation is $218.95. Order now.
