159090 Euchner Safety Accessories

Product Details

• Weight
  8.267325 lb
• Series
  Spare parts
• Product Class
  Accessories
• Mission time
  20
• Category
  4
• PFHD
  4.07 x 10⁻⁸ (Fixed failure rate without consideration of faults in wearing parts.)
• Diagnostic Coverage (DC)
  99
• B10D
  0,13 x 10⁶
• Safety Integrity Level
  SIL 3 (EN 62061:2005)
• Additional feature
  Incl. cover set ID. No. 120344
• Product version number
  V3.30.10
• Performance Level
  PL e
• Switching element
  2 pos. driven NC
• Version
  Emergency stop illuminated
• Assignment diagram
  B1
• Bus data protocol
  Profinet (IEC 61158 type 10)
• Assured release distance Sar
  max.65 mm
• Safety data protocol
  Profisafe (IEC 61784-3-3)
• Transponder coding
  Unicode
• Fusing
  min.1 A Slow blow
Auxiliary voltage DC
24 V DC -15% ... +10% (The auxiliary voltage is not required for the MGB system)
Operating voltage DC
24 V DC -15% ... 10% ((Reverse polarity protected, regulated, residual ripple <5%, PELV))
Rated insulation voltage Ui
75 V
Connecting cable
Profinet I/O cable, at least cat. 5e
EMC protection requirements
In accordance with EN 61000-4 and EN 61326-3-1
Safety class
III
Current consumption
max.500 mA
Rated impulse withstand voltage Uimp
0,5 kV
Housing material
Reinforced plastic, die-cast zinc nickel-plated, stainless steel
Degree of contamination (external, according to EN 60947-1)
3
Maximum feed-in current in the connection block
max.4000 mA
Locking force FZh
2000 N
Installation orientation
Door hinge DIN right
Guard locking principle
Closed-circuit current principle
Degree of protection
IP54
Connection
7/8" Power (X1 (The document PROFINET "Cabling and Interconnection Technology" from the PNO aids in the correct selection of wiring.))
Ambient temperature
-20 ... 55 °C
Reaction time
max.250 ms Switch-off time (The reaction time is the max. time between the change in the input status and the deletion of the corresponding bit in the bus protocol.)
Weight
3,1 kg
Switching frequency
0,25 Hz
Mechanical life
0,1 x 10⁶
Shock and vibration resistance
In acc. with EN 60947-5-3
