086419 Euchner Limit Switches
Part#:086419
Alt. Part#:SN04R12-514-MC1962
Manufacturer:Euchner
Category:Limit Switches
Product Lifecycle:Active
Product description
086419 Euchner - MULTIPLE LIMIT SWITCH
Product Details
- Weight 1.214955 lb
- B10D 2 x 10⁶
- Short circuit protection according to IEC 60269-1 6A gG
- Switching current min.5 mA
- Rated impulse withstand voltage Uimp 4 kV
- Connection cross-section 0,34 ... 1,5 mm²
- Rated insulation voltage Ui 250 V
- Thermal rated current Ith 10 A
- Utilization category acc. to EN 60947-5-1 2.5A 230V
- Actuating force min.25 N
- Roller diameter 8 mm
- Installation orientation Any
- Number of switching elements 4
- Actuating element Roller plunger (Ball bearing)
- Approach speed 0,01 ... 120 m/min
- Connection 2 x M20 x 1.5
- Number of NO contacts 4
- Number of positively driven contacts 4
- Design Upright
- Plunger spacing 12 mm
- Switching principle Snap-action switching contact
- Degree of protection IP67
- Mechanical life 1 x 10⁶
- Contact material Silver alloy, gold flashed
- Ambient temperature -5 ... 80 °C
- Housing material Die-cast aluminum, anodized
- Weight 0,5 kg
- Contact closing time ≤ 5ms
- Contact bounce time ≤ 3ms
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 086419 on MQ Automation is $1,269.18. Order now.
Similar products from: Euchner Limit Switches
Manufacturer warranty
086419 Euchner
$1,269.18
